HanWei Semiconductor Laser Welding Head Compatible with 30W to 4000W Laser Source
The welding head is intended for use with semiconductor laser sources and can be applied in processes such as metal sheet welding, large-part assembly welding, soldering work, and plastic material joining. Its structural configuration is developed around semiconductor laser transmission requirements, making it suitable for continuous manufacturing environments.
The product focuses on practical system matching while reducing unnecessary structural complexity. It provides an economical option for users requiring efficient laser welding capability in production lines, workshops, and customized automation equipment. The design supports straightforward installation and daily operation.
Key Features
- Cost-Conscious Configuration for Manufacturing Use.
- Built for Semiconductor Laser Integration.
- Optional SMA905, D80, and QBH Interfaces.
- Supports Semiconductor Lasers from 30W to 4000W.
- Integrated Cooling Layout and Enclosed Internal Assembly.
Technical Specifications
| Model |
HW-36-XXXXXX-T-QBH
|
HW-50-XXXXXX-F-QBH
|
| Usable Power |
200 W maximum
|
500-4000 W maximum
|
|
Collimating length
|
80/100/120/150/200
|
100 / 150 / Customized
|
|
Focus length
|
80/100/120/150/200
|
80/100/120/150/200
|
| Interface type |
SMA 905 / D80
|
SMA 905 / QBH
|
| Accessible wave range |
1064 |
1064 |
| Head Type |
F / T / Y
|
F / T / Y
|
| Net Weight |
1.1 kg
|
2.7 kg
|
|
Usable laser source
|
Diode laser source
|
Diode laser source
|
Application Advantages
The welding head can be configured for semiconductor laser systems covering a power range from 30W up to 4000W. This allows it to adapt to both lower-power precision processing and higher-power welding requirements within different manufacturing scenarios.
An internal water-cooling path is incorporated into the product structure to support heat management during operation. The internal assembly adopts a fully enclosed arrangement designed to reduce external dust influence on internal components while supporting long-duration equipment use.
